LOS ANGELES, Nov. 28, 2018 /PRNewswire-HISPANIC PR WIRE/ — With its bumper-to-bumper, wheels-to-roof transformation, the 2020 Toyota Corolla was already big news in sedans for 2019. And now comes the ultimate “But wait, there’s more!” bonus: a new hybrid model that achieves at least 50 mpg combined fuel economy (projected). That makes the 2020 Corolla Hybrid the most fuel-efficient model to ever wear the model name that debuted more than a half-century ago.

The design isn’t the only thing electrifying about the Corolla Hybrid. This high-efficiency model adapts the latest Toyota Hybrid Synergy Drive from the new-generation Prius, already proven as an MPG winner. Only Toyota offers such a distinct choice of hybrids in this vehicle segment, thus catering to customers who have different tastes in design but the same desire for maximum fuel efficiency.

The 2020 Corolla Hybrid, like its gas-powered siblings, delivers a highly-satisfying driving experience, along with the brand’s latest advances in comfort and multimedia technology. As on the 2020 Corolla gas models, the Toyota Safety Sense 2.0 suite of active safety systems comes standard.

The 2020 Corolla Hybrid is yet more evidence of Toyota’s indisputable global hybrid leadership, which began more than 20 years ago.

Fit for a Hybrid

The hybrid powertrain and battery were a natural fit for the new Corolla because of the Toyota New Global Architecture (TNGA) platform. There’s no compromise in cabin roominess, for example, when choosing the Corolla Hybrid versus a gas model.

The new hybrid system combines a 1.8-liter four-cylinder gasoline engine with two motor/generators through an electronically controlled planetary-type continuously variable transmission (CVT) transaxle. Combined system output of 121 horsepower yields decidedly responsive performance.

The nickel-metal hydride (Ni-MH) battery pack employs a newly developed technology called Hyper-Prime Nickel™ to boost battery performance in a smaller and lighter package. The battery’s smaller size and flatter shape allow it to be packaged under the rear seat, rather than taking up trunk space, and also allowing a 60/40 split folding rear seatback to expand cargo capacity. The battery location also contributes to the vehicle’s lower center of gravity, a boon to agility.

The engine, working in concert with the electric motor (MG2), assures responsive performance, while exemplary energy efficiency is achieved by using both electric motors (MG1 and MG2) for hybrid battery charging.

Driving the Corolla Hybrid

The Corolla Hybrid’s linear acceleration response may take some by surprise. When pulling away, the battery provides a subtle power boost in order to put less strain on the engine and eliminate the “rubber band” effect experienced with some hybrids.

A preload differential adds to the confident acceleration feel. During low loads and low differential rotation, differential-limited torque is distributed to the left and right wheels, yielding excellent handling stability. At mid-range and high engine loads, the preload differential functions as an open differential.

Corolla Hybrid has EV mode, which allows the vehicle to be operated as a pure electric vehicle for short distances, depending upon certain conditions, such as battery charge level. This mode is useful for operating the vehicle in parking lots or indoor parking garages, for example. The Vehicle Proximity Notification feature alerts pedestrians of the vehicle’s presence when running in battery mode.

Along with the expected NORMAL and ECO drive modes, a SPORT drive mode setting allows for an increase in power for stronger acceleration response when desired.

• NORMAL mode: Allows the hybrid system to achieve an ideal combination of fuel economy and vehicle acceleration. The accelerator opening amount changes linearly in response to accelerator pedal operation.
• ECO mode: Improves hybrid system efficiency by limiting power in response to light to moderate accelerator pedal input.
• SPORT mode: Available power is increased, allowing for improved acceleration response.

Stopping the Corolla Hybrid

Another boost to efficiency comes from the Electronically Controlled Brake (ECB) system, which coordinates operation between the regenerative braking force of the electric motors and the hydraulic braking system force to provide optimal stopping power. By proactively using the electric motors to recover as much electrical energy as possible from the regenerative braking system, this extremely efficient cooperative control helps to maximize fuel economy.

An active hydraulic booster on the conventional (non-regenerative) braking system improves pedal feel and feedback for the driver. Critically, should there ever be a malfunction in the ECB system, the conventional hydraulic braking system can stop the vehicle.

Brake Hold, when engaged, is a convenient technology that reduces driver effort while waiting at a traffic light or while driving in heavy traffic. When the driver presses the accelerator, Brake Hold releases instantly.

How the Other Half Works

The other half of the Hybrid Synergy Drive team, the gas engine, is no less impressive than the electric side. The 2ZR-FXE 1.8-liter inline four-cylinder engine was designed specifically for a hybrid application. The long-stroke configuration employs the Atkinson cycle, which uses a very high compression ratio (13.0:1) along with a shorter intake stroke and longer expansion stroke than the Otto cycle. The Atkinson cycle extracts more energy from the fuel, and the electric motors compensate for reduced low-end power (versus the Otto cycle).

Friction created by the piston skirts, rotating parts and oil pump is reduced, and an electric water pump eliminates the parasitic losses with a conventional belt-driven pump. Toyota sought efficiency gains in every system. The highly-efficient air conditioning system, for example, uses S-FLOW control, which automatically optimizes airflow throughout the cabin according to the temperature setting, actual cabin and outside temperatures, sunlight intensity, and occupied seats.

Getting the engine up to operating temperature quickly is critical to conserving fuel and reducing emissions at start-up. In the Corolla Hybrid, an exhaust heat recirculation system speeds up engine coolant warm-up. That in turn allows the hybrid system to stop the gas engine earlier and more often in the driving cycle when it’s not needed, for example in low-power-demand city driving conditions.

The PTC (Positive Temperature Coefficient) heater quickly provides cabin heat electrically in cold temperatures.

Hybrid Exclusives

The Corolla Hybrid rolls on 15-inch aluminum alloy wheels with low-rolling resistance tires. As on the Corolla gas models, the new multi-link rear suspension improves both handling agility and ride comfort compared to the previous-generation Corolla Sedan.

The instrument panel uses a high-grade meter with a 7-inch Multi-Information Display (MID). The MID shows the speedometer, as well as a hybrid system indicator/real-time battery charge status indicator. ECO accelerator guidance, also shown in the MID, can provide a guideline for maximizing fuel efficiency by coaching the driver on optimal accelerator pedal operation to match driving conditions. Drivers who like the visual appeal of seeing engine rpm can choose to display a tachometer.

Multimedia Mogul

The 2020 Corolla Hybrid’s multimedia offerings start with the standard Entune™ 3.0 Audio system that includes: 8-in. touchscreen display; six speakers; Apple CarPlay compatibility; Amazon Alexa; Entune 3.0 App Suite Connect; Safety Connect; Wi-Fi Connect; Scout GPS Link Compatible; Siri Eyes Free; auxiliary audio jack and USB 2.0 port with iPod connectivity and control; AM/FM; MP3/WMA playback capability; voice recognition training and tutorials; hands-free phone capability; voice recognition; music streaming via Bluetooth; customizable home screen, and weather/traffic information via Entune 3.0 App Suite.

Safety

The Corolla Hybrid features eight standard airbags and Toyota’s Star Safety System, which includes Enhanced Vehicle Stability Control, Traction Control, Electronic Brake-force Distribution, Brake Assist, Anti-lock Braking System, and Smart Stop Technology. All Corolla models come equipped with a standard backup camera.

Toyota Safety Sense 2.0

Significantly, all 2020 Corolla models are equipped as standard with Toyota Safety Sense™ 2.0, an advanced suite of integrated active safety features.

PCS (Pre-Collision System):  Is designed to automatically activate the brakes to help avoid a collision or mitigate the impact force. PCS is able to detect a vehicle or pedestrian in day and low-light conditions, as well as a bicycle during daylight.

Full-Speed DRCC (Dynamic Radar Cruise Control): Designed for highway use, designed to maintain a set vehicle-to-vehicle distance and is also capable of low-speed following up to speeds of about 24 mph. The Corolla can stop when the vehicle ahead comes to a stop, maintaining an appropriate distance to it.

LDA (Lane Departure Alert) w/ Steer Assist: Designed to give the driver audible and visual warnings and, if necessary, provides steering assistance if it detects the possibility of leaving the driving lane. It also detects excess weaving within the driving lane that might indicate driver distraction, inattention or drowsiness.

LTA (Lane Tracing Assist): LTA is enabled when LDA and DRCC are both on and active. LTA employs a lane centering function that will make constant steering inputs to help the driver keep the vehicle in its lane. LTA is designed for uses on relatively straight highways to preemptively avoid unwanted lane departures and reduce driver fatigue.

AHB (Automatic High Beam): When enabled, detects the headlights of oncoming vehicles and taillights of preceding vehicles and automatically switches between high and low beams as appropriate.

RSA (Road Sign Assist): Designed to recognize speed limit, Stop, Yield, and Do Not Enter signs and display them on the vehicles MID to help assist the driver.

About Toyota
Toyota (NYSE:TM) has been a part of the cultural fabric in the U.S. and North America for 60 years, and is committed to advancing sustainable, next-generation mobility through our Toyota and Lexus brands. During that time, Toyota has created a tremendous value chain as our teams have contributed to world-class design, engineering, and assembly of more than 36 million cars and trucks in North America, where we operate 14 manufacturing plants (10 in the U.S.) and directly employ more than 47,000 people (more than 37,000 in the U.S.).  Our 1,800 North American dealerships (nearly 1,500 in the U.S.) sold more than 2.7 million cars and trucks (2.4 million in the U.S.) in 2017 – and about 87 percent of all Toyota vehicles sold over the past 15 years are still on the road today.

Toyota partners with community, civic, academic, and governmental organizations to address our society’s most pressing mobility challenges. We share company resources and extensive know-how to support non-profits to help expand their ability to assist more people move more places. For more information about Toyota, visit www.toyotanewsroom.com.

Media Contact:
Zachary Reed
469-292-3499
[email protected]

Photo – https://mma.prnewswire.com/media/790447/Corolla_Hybrid_2020.jpg
Logo – https://mma.prnewswire.com/media/790667/Toyota_Corp_Red_Logo.jpg

SOURCE Toyota Motor North America

LOS ANGELES, Nov. 28, 2018 /PRNewswire-HISPANIC PR WIRE/ — When it comes to the 2019 Prius, “Let’s Go Places” can be expanded to “let’s go more places, in more conditions” thanks to the available new AWD-e system. Designed to provide more confidence and control when weather and road conditions are less than ideal, the electric all-wheel drive system further expands where the Prius can take drivers.

The new Prius AWD-e system will certainly deliver added traction and confidence for drivers but, in true Prius fashion, the 2019 AWD-e will lay claim to being one of the most fuel-efficient all-wheel-drive-equipped passenger cars available in the U.S., thanks to manufacturer-projected mpg estimates of 52 mpg city / 48 mpg highway / 50 mpg combined. Toyota estimates that the AWD-e model could account for as much as 25 percent of annual U.S. Prius sales.

Toyota’s AWD-e system is ideal for Prius. The automatic on-demand system does not require a center differential or other torque-apportioning device, nor does it need a front-to-rear driveshaft. Instead, the “e” in AWD-e stands for electric. The Prius AWD-e uses an independent electric, magnet-less rear motor (a Toyota first) to power the rear wheels from 0 to 6 mph, then when needed, up to 43 mph. This system provides the power to the rear wheels to pull away from a stop, yet the on-demand system recognizes when all-wheel-drive performance is not needed to provide great fuel economy.

The addition of the available AWD-e system is only part of the wider revision to the 2019 Prius, which debuts newly refined front and rear exterior styling, along with additional interior updates. Let’s not forget the front-wheel-drive (FWD) Prius will still offer the impressive fuel economy for which it is known, with manufacturer-projected fuel economy estimates of 58 mpg city / 53 mpg highway / 56 mpg combined on the L Eco grade, while the LE, XLE and Limited has projected fuel ratings of 54 mpg city / 50 mpg highway / 52 mpg combined.

The 2019 Prius also adopts the familiar model grade strategy used throughout the Toyota family, dropping the numerals in favor of grade labels L Eco, LE, XLE and Limited. Prius will also sport two new colors for 2019, Supersonic Red and Electric Storm Blue. The AWD-e model will be offered in LE and XLE grades and will debut a new two-tone 15-inch alloy wheel (with cover).

The AWD-e models use a newly developed compact Nickel-Metal Hydride (Ni-MH) battery that is designed to provide excellent performance in cold-weather conditions. The AWD-e battery fits under the rear seat area and does not impact the luggage capacity. The FWD models will tout a Lithium Ion battery.

The Prius AWD-e models offer the same 65.5 cu. ft. of carrying space with the standard 60:40 split rear seatbacks lowered as other Prius models. That’s more than in some small SUVs and larger than most full-size sedans. Expanding carrying options, the Prius AWD-e will offer available Genuine Toyota Accessory cargo crossbars for roof rack attachments, such as for carrying bikes, kayaks, snowboards, or a cargo carrier. The Prius AWD-e XLE features upgraded SofTex-trimmed, heated front seats with 8-way power-adjustable driver’s seat.

The SofTex-trimmed heated tilt/telescopic steering wheel features surface temperature-regulating properties to help make it feel more comfortable in hot or cold weather. The steering wheel also integrates switches for the Entune Audio system, Multi-Information Display, and Bluetooth hands-free phone controls.

The Prius comes standard with driver’s door Smart Key System, Push Button Start and remote illuminated entry. The XLE and Limited grades include Standard Smart Key System on three doors. An Adaptive Front Lighting System is available on the XLE grade and is standard on the Limited grade. And, Toyota Safety Connect, standard on Limited models, includes Emergency Assistance, Stolen Vehicle Locator, Roadside Assistance and Automatic Collision Notification and comes with a complimentary three-year trial subscription.

Standard Toyota Safety Sense
All 2019 Prius models, including the Prius AWD-e versions, come standard with Toyota Safety Sense P (TSS-P). Using millimeter-wave radar and a monocular camera sensor to help detect a pedestrian, a vehicle, and lane markers and headlights in the surrounding area, TSS-P provides a comprehensive bundle of active safety features including: Pre-Collision System with Pedestrian Detection (PCS w/ PD), Lane Departure Alert with Steering Assist (LDA w/ SA), Automatic High Beams (AHB), and Full-Speed Range Dynamic Radar Cruise Control (DRCC).

Because all Prius models, under certain circumstances, can operate in battery mode alone, during which they make little to no noise, they incorporate a Vehicle Proximity Notification System (VPNS) to help alert pedestrians and cyclists.

High Tech Galore
All Prius models share interior features including the familiar central screen interface. The 4.2″ color Dual Multi-Information Display with customizable screens adds an AWD-e system indicator to the menu of displays, which also includes Energy Monitor, Hybrid System Indicator and Eco Score, Eco Savings Record, Drive Monitor, Eco Wallet, Eco Diary, Climate Control, driver support systems, audio system content, and navigation system content. For the ultimate in high-tech information, the available Color Head-Up Display (HUD) shows the speedometer, navigation, and Hybrid System Indicator in the driver’s line of sight.

The standard Entune Audio system for AWD-e models includes the Entune Multimedia Bundle: 6.1 in. touch-screen display, AM/FM CD player, 6 speakers, auxiliary audio jack, one USB 2.0 port with iPod connectivity and two 2.1-amp USB charge ports, advanced voice recognition, Bluetooth hands-free phone capability, phone book access and music streaming, Siri Eyes Free, and an integrated backup camera display. The Limited grade comes standard with the Entune Premium JBL Audio with Integrated Navigation and App Suite, with a large 11.6″ HD multimedia display.

2019 Prius Mechanical Features
The Prius AWD-e shares the Hybrid Synergy Drive system with other Prius models. The system combines the output of a 1.8-liter 4-cylinder gasoline engine and two motor/generators through an electronically controlled planetary-type continuously variable transmission (CVT). The Electronically Controlled Brake System coordinates control between the regenerative braking and the vehicle’s hydraulic brake force to provide optimal brake performance and feel.

The 2ZR-FXE 1.8-liter 4-cylinder gasoline engine is itself a paragon of high efficiency. Thanks to ultra-low internal friction and efficient combustion, it exceeds 40 percent thermal efficiency, which is among the highest in the world for a gasoline engine.

The Prius gets a good share of its fuel efficiency by cheating the wind with an ultra-low 0.24 coefficient of drag (Cd), which is among the lowest of current production passenger cars. An automatic grille shutter reduces drag by closing when airflow to the radiator is not needed. Even the air conditioning system, which uses a quiet electric compressor, works intelligently to maximize energy efficiency. The Smart-flow (S-FLOW) mode directs airflow only to seated occupants to conserve energy and maximize comfort.

Standard Bi-LED headlamps and LED rear combination lamps reduce energy consumption compared to halogens, while giving better light and having a longer service life. A backup camera comes standard on all grades, and a full-width glass panel beneath the rear spoiler aids rearward visibility while also serving as a distinctive design feature.

Toyota New Global Architecture
The fourth-generation Prius is built around the Toyota New Global Architecture (TNGA). The platform introduced a new high-strength body structure, multi-link rear suspension and a lower center of gravity. The result for the Prius is a highly engaging driving experience combined with exemplary ride smoothness and a quiet cabin.

Hot-stamped and high tensile steels, which allow for intricate forms that are both lightweight and strong, are used extensively throughout the body. Aluminum components, including the hood and rear doorframes and brake calipers, help keep vehicle weight low. Innovative fastening methods, including laser screw welding and advanced adhesives, contribute to structural strength.

Peace-of-Mind Warranty Protection
Toyota’s 36-month/36,000 mile basic new-vehicle warranty applies to all components other than normal wear and maintenance items. A 60-month warranty covers the powertrain for 60,000 miles and against corrosion with no mileage limitation. The hybrid-related components, including the HV battery, battery control module, hybrid control module and inverter with converter, are covered for 96 months/100,000 miles.

The Prius also comes standard with ToyotaCare, a complimentary plan covering normal factory-scheduled maintenance for two years or 25,000 miles, whichever comes first. For Prius, the complimentary 24-hour roadside assistance is extended to three years (over the standard two years on other models).
